Circulating water pump selection requirements
Today, a customer wanted to purchase a circulating water pump, initially considering a jet pump. He provided the following information:
Circulating water, suction lift 0-18m, power 2800W, flow rate 5.3m³/h, head 100m, voltage 220V, material 304.
The on-site self-priming jet pump, JET-2800, was used. We wanted to see if we had a jet pump that matched the customer's requirements.
However, our technicians found that our jet pump could not meet the required range. We asked if he would be willing to use our vertical multistage centrifugal pump.
Here are the specific specifications of the vertical multistage centrifugal pump:
32CDL4-160
Vertical Multistage Centrifugal Pump
Media: Water
Flow rate: 5.3m³/h
Head: 100m
Power: 3kW-2P (AC380V, 50Hz, 3PH, F, IP55, YE3)
Speed: 2900rpm
Diameter: 32mm
Seal: Mechanical seal
Pump head material: SS304
Base material: Cast Iron
Flange: Cast Iron
If you have specific requirements for circulating
water pumps, booster pumps, or industrial pumps, please contact CIXIFM Winny:
Email: sales01@cxflowmeter.com
WhatsApp: 008618049841995
