CDL/CDLF Series vertical multi-stage centrfugal pump
Summary
CDL/CDLF vertical multistage centrifugal boosting pump,
which are multi-functional products. The pressure resistant
cylinder and flow passage components are fixed between
pump head and inlet/outlet sections with tie-bar bolts. The
inlet and outlet are located at the pump bottom at the same
plane. This kind of pump can be equipped with an intelligent
protector to effectively prevent it from dry-running, out of
phase and overload. They can be used to convey various
mediums from tap water to industrial liquid at different
temperature and with different flow rate and pressure. CDL
type is applicable to conveying non-corrosive liquid, while
CDLF is suitable for slightly corrosive liquid.
Application
1. Water supply: water plant filtration and transmission,
water plant divisional water supply, main pressurization,
high-rise building pressurization.
2. Industrial pressurization: process water system, cleaning
system high pressure flushing system,fire protection system.
3. Industrial liquid transportation: cooling and air
conditioning systems, boiler feed water and condensing
systems, machine tool accessories, acids and alkalis.
5. Water treatment: ultrafiltration system, reverse osmosis
system,distillation system, separator, swimming pool.
7. Irrigation: farmland irrigation, sprinkler irrigation, drip
irrigation.
8. Firefighting systems
Please tell us the measured medium, head, flow range and power supply at your site,
and we will recommend the most suitable product model for you.
Model Meaning
