Chemical Low Flow Meter High Frequency Flow Meter

High frequency gear flow meter high viscosity liquid flow meter


Product features

Small vibration and noise during operation, easy to install
Measure liquid
viscosity up to: 10000pa.s
Measuring accuracy: 0.5
Measuring range width up to: 100:1
Power supply: 5-26 VDC
Working temperature: -40~80 °C
Pressure: 32bar, custom high pressure
Output signal: ultra-high frequency square wave pulse output

Function introduction

For high viscosity medium, it is necessary to carry out precise measurement of trace liquid under low resistance (pressure loss). Even in the case of extremely slow gear rotation, a small amount of rotation can still give enough pulse number.


Medium

Glue	Epoxy resin	Butter	3 m glue	Hydraulic oil	Paint
Glass glue	Lubricating oil	Curing agent	Coating	Gear oil	Isocyanate
Polyether polyols	Stearic acid liquid	An unknown liquid	Chemical solvent	Asphalt	The silicone
Aqueous solution of poly	(vinyl alcohol)	One-component adhesive	Oil and grease	Polyurethane (pu)	Frozen oil
Grease	Industrial oil	Concentrate	Isolation agent	UV glue	Anaerobic adhesive.......




Model	Resolution	Connection size	Flow range	Gear material	Shell material
G0.015AL-HR-SW	0.00025ml/P	G1/8	0.004~500mL/min	SS316L	AL
G0.025AL-HR-SW	0.0006ml/P	G1/8	0.008~1L/min	SS316L	AL
G0.04AL-HR-SW	0.0008ml/P	G1/4	0.02~2L/min	SS316L	AL
G0.2AL-HR-SW	0.003ml/P	G3/4	0.16~8L/min	SS316L	AL
G0.4AL-HR-SW	0.006ml/P	G1/2	0.2~20L/ min	SS316L	AL
G1.0AL-HR-SW	0.01ml/P	G1/2	0.4~40L/ min	SS316L	AL
G2.0AL-HR-SW	0.02ml/P	G3/4	1~60L/min	SS316L	AL
