G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor

G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor

G Series Micro Flow Meter High Viscosity Fluid Flow Meter Glue Resin Flow Sensor

  • G series gear flow meters are used for flow measurement and detection of all high viscosity liquid fluids, glues, plastics, polyurethane hot melt adhesives,resin,ABS,molasses etc.

    Support customization, if you have any questions, please contact: info@cxflowmeter.com


        Min flow 0.005L/min

        Max resolution 0.015p/min

        Wide range and Ratio 1:500

        Ball/PEEk bear for more applications

        High accuracy 0.5% F.S

    INQUIRY
    The positive gear flowmeter have higher resolution and lower pressure loss than oval gear flowmeter
    The same principle but with a higher speed and can test higher viscosity medium
    Cooperate with DC8S displayer to display,output and control functions

    MEDIUM：
    Grease,Resin,Oil,Glue,Polyurethane Lubricating oil,Electrolyte,Coolant Chemicals,etc.Corrosive liquid....

    APPLICATIONS：
    Robot dispensing,dispensing machine injector test bench,hot melt,adhesive foaming agent ,hydraulic leak ,etc.

    01-BALL BEAR


    02-PEEK BEAR


    BASIC TECHANICAL
    1. Accuracy：+/-0.5FS
    2. Temperature：-30~80℃
    3. Pressure：50Bar(standard)
    4. Output：Pulse
    5. Power supply：4-26VDC
    6. Material：Stainless steel 316L or Aluminium
    7. Gear Material：Stainless steel 316L
    8. Bear：Ball bear or PEEK bear
    9. Connection：Thread conenction
